Ultrasonic Radar System Using Arduino (Automation Project)

  Back To Blogs

In this project, an Arduino is used to control a servo motor that sweeps an ultrasonic distance sensor back and forth. The distance to obstacles is measured using the sensor, and the information is used to trigger different levels of buzzer alerts. This system is useful in applications where obstacle detection and varying levels of alerts are needed.

Project : 48



                                      Obstacle Detection System with Servo and Buzzer

                                                                                             Figure :1
                                                                                   Figure: 2

Schematic Diagram :

PCB Diagram :

Introduction

In this project, an Arduino is used to control a servo motor that sweeps an ultrasonic distance sensor back and forth. The distance to obstacles is measured using the sensor, and the information is used to trigger different levels of buzzer alerts. This system is useful in applications where obstacle detection and varying levels of alerts are needed.

Components Required

1.     Arduino Board:



The main control unit that processes sensor data and controls the servo and buzzer.


2.       Ultrasonic Distance Sensor (HC-SR04):

Measures the distance to obstacles.
3.       Servo Motor:
Sweeps the ultrasonic sensor across a range of angles.

1.     Buzzer:




Provides auditory alerts based on obstacle proximity
1.       Connecting Wires:
To connect the sensor, servo, and buzzer to the Arduino.1.     Power Supply: To power the Arduino and other components.

Pin Configuration

·        Ultrasonic Sensor:

o    Trigger Pin (Trig) connected to Arduino pin 2.

o    Echo Pin connected to Arduino pin 3.

·        Servo Motor: Connected to Arduino pin 6.

·        Buzzer: Connected to Arduino pin 9.


Libraries Used

·        Servo: For controlling the servo motor.

Code

#include <Servo.h>



// Pin definitions const int trigPin = 2; const int echoPin = 3; const int servoPin = 6;

const int buzzerPin = 9;



// Variables for distance measurement long duration;

int distance;

Servo myServo; void setup() {

pinMode(trigPin, OUTPUT); pinMode(echoPin, INPUT);

pinMode(buzzerPin, OUTPUT); Serial.begin(9600);

myServo.attach(servoPin);

}

void loop() {

// Sweep servo from 15 to 165 degrees for (int i = 15; i <= 165; i++) {

myServo.write(i); delay(30);

distance = calculateDistance(); handleBuzzer(distance);

Serial.print(i);

Serial.print(",");

Serial.print(distance); Serial.print(".");

}

// Sweep servo from 165 to 15 degrees for (int i = 165; i >= 15; i--) {

myServo.write(i); delay(30);


distance = calculateDistance(); handleBuzzer(distance);

Serial.print(i);

Serial.print(",");

Serial.print(distance); Serial.print(".");

}

}

int calculateDistance() {

digitalWrite(trigPin, LOW); delayMicroseconds(2);

digitalWrite(trigPin, HIGH); delayMicroseconds(10);

digitalWrite(trigPin, LOW);

duration = pulseIn(echoPin, HIGH); distance = duration * 0.034 / 2; return distance;

}

void handleBuzzer(int distance) { if (distance > 39) {

digitalWrite(buzzerPin, LOW);

}

else if (distance <= 40 && distance > 20) {


beepBuzzer(150);

} else if (distance <= 20 && distance > 10) { beepBuzzer(70);

} else if (distance <= 10) { beepBuzzer(10);

}

}

 void beepBuzzer(int delayTime) { for (int j = 0; j < 6; j++) {

digitalWrite(buzzerPin, HIGH); delay(delayTime);

digitalWrite(buzzerPin, LOW); delay(delayTime);

}

}


Working

1.     Initialization:

o    The Arduino initializes serial communication at 9600 baud.

o    The servo motor and buzzer are set up with their respective pins.

o    The Servo library is used to control the servo motor, and the distance sensor is initialized.

2.     Main Loop:

o    The servo motor sweeps the ultrasonic sensor from 15 to 165 degrees and then back.


o    During each sweep, the distance to the closest obstacle is measured.

   o    Based on the distance, the buzzer provides alerts:

§  If the distance is greater than 39 cm, the buzzer is off.

§  If the distance is between 40 cm and 20 cm, the buzzer beeps with a delay of 150ms.

§  If the distance is between 20 cm and 10 cm, the buzzer beeps with a delay of 70ms.

§  If the distance is less than 10 cm, the buzzer beeps with a delay of 10 ms.

 o    The servo motor angle and distance measurements are output to the Serial Monitor.

3.     Distance Calculation:

o    The calculateDistance() function triggers the ultrasonic sensor and calculates the distance based on the time taken for the echo to

return.

4.     Buzzer Handling:

o    The handleBuzzer() function determines the appropriate buzzer alert based on the measured distance.

5.     Buzzer Beeping:

o    The beepBuzzer() function creates a sequence of beeps for a specified delay time.

Testing


1.     Setup: Assemble all components as per the pin configuration.

2.       Power Up: Power the Arduino and ensure all components are properly connected.

3.       Sensor Testing: Place obstacles at various distances to test the sensor's response and verify that the buzzer alerts correspond to the distances.


4.       Servo Movement: Observe the servo sweeping action and ensure that it covers the intended range.

5.     Monitoring: Continuously monitor the distance readings on the Serial Monitor and check if the buzzer alerts match the expected behavior.

Conclusion

The Obstacle Detection System with Servo and Buzzer project successfully

demonstrates how to integrate a servo motor, ultrasonic sensor, and buzzer to create a real-time obstacle detection and alert system. The project provides a practical example of how to combine different components for effective

environmental monitoring and alerting, showcasing the versatility of Arduino- based projects in practical applications.


Team Members:

1) Aadarasha

2) Aman

3) Annie

4) Bidhya
5) Rijan

6) Samikshya

7) Sauravi


College : Nepathya College,Tilottama-5
